Product specifications
●Body length: 1356mm
●Body height: 358mm
●Body width: 187mm
●Main rotor length: 650-730mm
●Main rotor diameter: 1542mm
●Tail rotor length: 105-115mm
●Tail rotor diameter: 279mm
●Motor pulley: 22T
●Pulley: 50T
●Front drive spindle: 15T
●Main gear: 62T
Tail drive main gear: 27T
● Tail gear: 23T
●Gear ratio: 9.38:1:4.83
●Maximum main rotor speed: 2400RPM
●Flying weight (including battery): about 5kg (ALIGN 12S 5200mAh)
Product Accessories
●TB70 empty kit set x 1
●700 carbon fiber main rotor x 1 set
●105 carbon fiber tail rotor x 1 set
●850MX brushless motor (540KV/4535) x 1
●DS820M High Voltage Brushless Servo x 3
●DS825M High Voltage Brushless Servo x 1
●Platinum HV 200A V4 brushless constant speed governor x 1
產品描述
●機身長:1356mm
●機身高:358mm
●機身寬:187mm
●主旋翼長:650-730mm
●主旋翼直徑:1542mm
●尾旋翼長:105-115mm
●尾旋翼直徑:279mm
●馬達皮帶輪:22T
●皮帶輪:50T
●前傳動主軸:15T
●主齒輪:62T
●尾驅動主齒:27T
●尾翼傳動齒:23T
●齒輪傳動比:9.38:1:4.83
●最大主旋翼轉速:2400RPM
●飛行重量(含電池):約5kg(ALIGN 12S 5200mAh)
商品配件
●TB70 空機套件組 x 1
●700 碳纖主旋翼 x 1 組
●105 碳纖尾旋翼 x 1組
●850MX 無刷馬達(540KV/4535) x 1
●DS820M 高壓無刷伺服器 x 3
●DS825M 高壓無刷伺服器 x 1
●Platinum HV 200A V4 無刷定速調速器 x 1
